Open Access | Case Report
This work is licensed under a Creative Commons Attribution-ShareAlike 4.0 International License.
Role of Low-Level Laser Therapy in Z-plasty
*Corresponding author: Ravi Kumar Chittoria
Mailing address: Department of Plastic Surgery, Jawaharlal
Institute of Postgraduate Medical Education and Research
(JIPMER), Pondicherry 605006, India.
Email: drchittoria@yahoo.com
Received: 16 December 2019 Accepted: 16 April 2020
DOI: 10.31491/CSRC.2020.06.054
Abstract
Z-plasty is a commonly performed procedure in plastic surgery. Flap necrosis is an important complication that may occur, and various precautions have been described to prevent it. Several studies have been conducted to establish the role of low-level laser therapy (LLLT) in local flap survival. We would like to discuss the role of LLLT in Z-plasty.
Keywords
Low-level laser therapy (LLLT); Z-plasty
Introduction
Z-plasty, a procedure introduced by Denonvillers in
1856, is commonly performed by plastic and reconstructive surgeons [1]. It consists of the transposition of two
interdigitating triangular flaps [1].
Tip necrosis is one of the most common complications
in Z-plasty. It may occur due to an inappropriate angle,
inadequate thickness of the flaps, the site of surgery, the
handling of tissue by surgeon, and the laxity of the surrounding skin. Tension in the flaps can invariably lead to
tip necrosis. Various modifications and precautions have
been described to prevent this complication.
We used low-level laser therapy (LLLT) during a Z-plasty
procedure on a patient to prevent tip necrosis. We report
this case because we have found no similar reports in
the literature.
Case Report
A 24-year-old female patient was admitted to the plastic surgery department of a tertiary care center. The patient had history of thermal burn, following which she developed a band contracture extending across the distal interphalangeal joint crease of the left ring finger with an apparent defect of 0.5 cm and a true defect of 0.75 cm. Two adjacent Z-plasty with each limb of 1cm leading to four transposition flaps were performed, as a single Z-plasty would have required a greater limb length (figure 1). The little finger was treated by soft tissue distraction using a Joshi’s external stabilization system (JESS) fixator.
LLLT was applied to the flaps intraoperatively using a continuous gallium arsenide (GaAs) diode red laser beam with a frequency of 10 kHz, a wavelength of 650 nm, and output power of 100 mW. The energy density used was calculated as 2.5 J/cm2 . It’s a non-contact device that delivers a laser beam in scanning mode. The distance between the laser source and the wound is 60 cm. LLLT was applied to the Z-plasty flaps for 125 s each time [2]. A regular dressing was applied to the suture line. LLLT was repeated five times, once every three days (Figure 2). The suture was removed on postoperative day 10. The flaps were rechecked three weeks later (Figure 3).
Results
All the flaps healed well. No complications were noted at three weeks.
Discussion
Z-Plasty is a surgical procedure whereby two interdigitating
triangular flaps are transposed. Z-plasty produces change in
the direction of the scar and also gives gain in length along
the direction of the common limb of the ‘Z’ [3]. Various contractures, such as oral commissure contractures, cicatricial
bands hindering joint mobility, and axillary burn synechiae,
can be treated by Z-plasty. The flap angles can range from 30
to 90 degrees. With angles less than 30 degrees, tip necrosis
may occur. Flaps with angles greater than 75 degrees are difficult to rotate and can result in increased tension and dog-ear
formation. Certain defects require variations in traditional
Z-Plasty with the use of unequal flap angles.
Tip necrosis is a known complication of Z-plasty. This leads to
healing by secondary intention and further scarring. Methods
of prevention include meticulous handling, proper planning,
and surrounding tissue laxity.
Our patient had a scarred surrounding skin area due to burns.
For this reason, we performed multiple Z-plasty as scar tissue might have limited the transposition of flaps and caused
suture line tension. We decided to use LLLT as an adjunctive
procedure to prevent flap tip necrosis.
LLLT, also known as phototherapy or photobiomodulation,
refers to the use of photons at a non-thermal irradiance to
alter biological activity [4]. The role of LLLT in wound healing has been established by various in vivo and in vitro studies.
Its role in stimulating hair growth in alopecia has also been
widely studied.
There are various mechanisms whereby the desired effects
of LLLT are obtained. At low doses, LLLT has been shown to
promote the proliferation of fibroblasts [5-8], keratinocytes [9],
endothelial cells [10], and lymphocytes [11, 12]. The mechanism
of proliferation is thought to be triggered by an increase in
growth factors due to the upregulation of transcription factors
and the activation of signaling pathways in the mitochondria
by photostimulation [5, 13-16]. Moreover, LLLT enhances neovascularization, promotes angiogenesis, and increases collagen synthesis, contributing to acute [17] and chronic wound
healing [18-20]. Due to its beneficial effects, it can be used for the
prevention of local flap failure. Various animal studies on the
role of LLLT in local flap survival have shown that it improves
microcirculation, leading to good results [21].
Conclusion
We suggest that LLLT can be used in Z-plasty as an adjunctive therapy to improve microcirculation, thereby increasing the chances of flap survival. However, large randomized control trials are required to establish its exact role.
Declaration
Conflicts of interest
All authors declared that there are no conflicts of interest.
References
1. Barreiros, H., & Goulao, J. (2014). Z-Plasty: useful
uses in dermatologic surgery. Anais brasileiros de
dermatologia, 89(1), 187-188.
2. Gaida, K., Koller, R., Isler, C., Aytekin, O., Al-Awami, M.,
Meissl, G., & Frey, M. (2004). Low level laser therapy—a
conservative approach to the burn scar?. Burns, 30(4),
362-367.
3. McGregor, I. A., & McGregor, A. D. (2000). Fundamental
techniques of plastic surgery: and their surgical
applications. Churchill Livingstone.
4. Avci, P., Gupta, A., Sadasivam, M., Vecchio, D., Pam, Z., Pam,
N., & Hamblin, M. R. (2013, March). Low-level laser (light)
therapy (LLLT) in skin: stimulating, healing, restoring.
In Seminars in cutaneous medicine and surgery (Vol. 32,
No. 1, p. 41). NIH Public Access.
5. Lubart, R., Wollman, Y., Friedmann, H., Rochkind, S., &
Laulicht, I. (1992). Effects of visible and near-infrared
lasers on cell cultures. Journal of Photochemistry and
Photobiology B: Biology, 12(3), 305-310.
6. Yu, W., Naim, J. O., & Lanzafame, R. J. (1994). The effect
of laser irradiation on the release of bFGF from 3T3
fibroblasts. Photochemistry and photobiology, 59(2),
167-170.
7. Vinck, E. M., Cagnie, B. J., Cornelissen, M. J., Declercq, H. A.,
& Cambier, D. C. (2003). Increased fibroblast proliferation
induced by light emitting diode and low power laser
irradiation. Lasers in medical science, 18(2), 95-99.
8. Frigo, L., Fávero, G. M., Lima, H. J. C., Maria, D. A., Bjordal,
J. M., Joensen, J., ... & Lopes-Martins, R. A. B. (2010).
Low-level laser irradiation (InGaAlP-660 nm) increases
fibroblast cell proliferation and reduces cell death in
a dose-dependent manner. Photomedicine and Laser
Surgery, 28(S1), S-151.
9. Basso, F. G., Oliveira, C. F., Kurachi, C., Hebling, J., & de
Souza Costa, C. A. (2013). Biostimulatory effect of lowlevel laser therapy on keratinocytes in vitro. Lasers in
medical science, 28(2), 367-374.
10. Szymanska, J., Goralczyk, K., Klawe, J. J., Lukowicz,
M., Michalska, M., Goralczyk, B., ... & Rosc, D. (2013).
Phototherapy with low-level laser influences the
proliferation of endothelial cells and vascular endothelial
growth factor and transforming growth factor-beta
secretion. J Physiol Pharmacol, 64(3), 387-391.
11. Moore, P., Ridgway, T. D., Higbee, R. G., Howard, E. W.,
& Lucroy, M. D. (2005). Effect of wavelength on lowintensity laser irradiation-stimulated cell proliferation
in vitro. Lasers in Surgery and Medicine: The Official
Journal of the American Society for Laser Medicine and
Surgery, 36(1), 8-12.
12. Agaiby, A. D., Ghali, L. R., Wilson, R., & Dyson, M. (2000).
Laser modulation of angiogenic factor production by Tlymphocytes.Lasers in Surgery and Medicine: The Official
Journal of the American Society for Laser Medicine and
Surgery, 26(4), 357-363.
13. Stadler, I., Evans, R., Kolb, B., Naim, J. O., Narayan, V.,
Buehner, N., & Lanzafame, R. J. (2000). In vitro effects of
low-level laser irradiation at 660 nm on peripheral blood
lymphocytes. Lasers in Surgery and Medicine: The Official
Journal of the American Society for Laser Medicine and
Surgery, 27(3), 255-261.
14. Saygun, I., Nizam, N., Ural, A. U., Serdar, M. A., Avcu, F., &
Tözüm, T. F. (2012). Low-level laser irradiation affects the
release of basic fibroblast growth factor (bFGF), insulinlike growth factor-I (IGF-I), and receptor of IGF-I (IGFBP3)
from osteoblasts. Photomedicine and laser surgery, 30(3),
149-154.
15. Esmaeelinejad, M., & Bayat, M. (2013). Effect of lowlevel laser therapy on the release of interleukin-6 and
basic fibroblast growth factor from cultured human skin
fibroblasts in normal and high glucose mediums. Journal
of Cosmetic and Laser Therapy, 15(6), 310-317.
16. de Sousa, A. P. C., Paraguassú, G. M., Silveira, N. T. T., de
Souza, J., Cangussú, M. C. T., dos Santos, J. N., & Pinheiro,
A. L. B. (2013). Laser and LED phototherapies on
angiogenesis. Lasers in medical science, 28(3), 981-987.
17. Chen, C. H., Tsai, J. L., Wang, Y. H., Lee, C. L., Chen, J. K., &
Huang, M. H. (2009). Low-level laser irradiation promotes
cell proliferation and mRNA expression of type I collagen
and decorin in porcine achilles tendon fibroblasts in
vitro. Journal of Orthopaedic Research, 27(5), 646-650.
18. Isman, E., Aras, M. H., Cengiz, B., Bayraktar, R., Yolcu,
U., Topcuoglu, T., ... & Demir, T. (2015). Effects of laser
irradiation at different wavelengths (660, 810, 980, and
1064 nm) on transient receptor potential melastatin
channels in an animal model of wound healing. Lasers in
medical science, 30(5), 1489-1495.
19. Yu, W., Naim, J. O., & Lanzafame, R. J. (1997). Effects
of photostimulation on wound healing in diabetic
mice. Lasers in Surgery and Medicine: The Official
Journal of the American Society for Laser Medicine and
Surgery, 20(1), 56-63.
20. Dadpay, M., Sharifian, Z., Bayat, M., Bayat, M., & Dabbagh,
A. (2012). Effects of pulsed infra-red low level-laser
irradiation on open skin wound healing of healthy and
streptozotocin-induced diabetic rats by biomechanical
evaluation. Journal of Photochemistry and Photobiology
B: Biology, 111, 1-8.
21. Kubota, J., & Ohshiro, T. (1996). The effects of diode laser
LLLT on flap survival: measurement of flap microcirculation
with laser speckle flowmetry. Laser Therapy, 8(4), 241-
246.
